Double Adhesive Tape
Description
Earth Composites’ Double Adhesive Tape is a high-performance double-sided adhesive tape specially designed for composite manufacturing, vacuum bagging, resin infusion, tooling, mold assembly, and industrial bonding applications. Engineered with a strong pressure-sensitive adhesive on both sides, it delivers excellent bonding strength, dimensional stability, and reliable adhesion to metals, composites, plastics, and tooling surfaces. Compatible with demanding composite processes, it provides clean application, easy handling, and consistent performance, making it an ideal solution for wind energy, aerospace, marine, automotive, railway, and industrial composite manufacturing environments.
Technical Specifications
| Property | Specification |
|---|---|
| Material | Double-Sided Acrylic Adhesive Tape |
| Product Type | Double Adhesive Tape |
| Adhesive Type | High-Performance Pressure Sensitive Acrylic Adhesive |
| Carrier Material | Polyester (PET) Film / Tissue Carrier |
| Total Thickness | 0.10 mm – 0.25 mm (Custom Available) |
| Width | 6 mm – 1000 mm (Custom Width Available) |
| Roll Length | 25 m / 50 m / Custom Roll Length |
| Color | Transparent / White |
| Operating Temperature | -20°C to +120°C |
| Initial Tack | Excellent |
| Bond Strength | High Shear & Peel Adhesion |
| Surface Compatibility | Metals, FRP, Composite Laminates, Plastics, Glass & Tooling Surfaces |
| Chemical Resistance | Excellent Resistance to Moisture, Oils & Industrial Chemicals |
| Applications | Composite Manufacturing, Vacuum Bagging, Tooling, Mold Assembly, Fixture Mounting & Industrial Bonding |
| Storage Condition | Store in a cool, dry place below 30°C away from direct sunlight and humidity. |
